DCA800SSK2 60 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #0 (09/03/09) — PAGE 57
GENERATOR ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 C5110000402 ROTOR ASSY. ........................................ 1 ...........INCLUDES ITEM W/#
1-1# FIELD ASSY. 1
1-2# 0601842366 RESISTOR, 80W 50K

4
1-3# 8171020004 INSULATOR WASHER 6
1-4# 8171020504 INSULATOR WASHER 6
1-5# C5111100002 FAN 1
1-6# C5163400003 COUPLING RING 1
1-7# 0010312025 HEX HEAD BOLT 2
1-7A# 0042512000 WASHER, LOCK 2
1-8# C5163100104 COUPLING DISK ASSY. 1
1-9# C5163200004 COUPLING HUB WASHER 1
1-10# C5111300003 BALANCING PLATE ............................... 1 ...........PURCHASE ITEM 1-17 AS A SET
1-11# 0012724060 HEX HEAD BOLT 10
1-12# 0042524000 WASHER, LOCK 10
1-13# 8461026023 RECTIFIER SET PLATE ......................... 1 ...........PURCHASE ITEM1-17 AS A SET
1-14# 0601823282 RECTIFIER 2
1-15# 0018205020 HEX SOCKET HEAD CAP SCREW 4
1-15A# 0040005000 WASHER, LOCK 4
1-15B# 0041205000 WASHER, FLAT 4
1-16# 0010112020 HEX HEAD BOLT 6
1-16A# 0040012000 WASHER, LOCK 6
1-17# 0601000209 BALANCING WEIGHT KIT 1
1-18 C5111500003 BEARING FLANGE 1
1-19 0072906322 BEARING 1
1-20 0080000110 SNAP RING 1
1-21# C5153300104 BEARING GASKET 1
2 0012116065 HEX HEAD BOLT 10
2A 0042516000 WASHER, LOCK 10
3 C5130000003 STARTER ASSY. 1
31 C5131200404 CLAMPER 4
32 C5131200014 CLAMPER 4
33 C5131200504 CLAMPER 2
34 0016310090 HEX HEAD BOLT 4
34A 0030010000 HEX NUT 4
34B 0040010000 WASHER, LOCK 8
34C 0041210000 WASHER, FLAT 4
35 0017110020 HEX HEAD BOLT 8
4 C5153000002 END BRACKET 1
5 C4137000003 EXCITER FIELD ASSY 1
6 0012110075 HEX HEAD BOLT 6
6A 0042610000 WASHER, LOCK 6
6B 0041210000 WASHER, FLAT 6
7 0845044904 GROMMET 1
