DCA800SSK2 60 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #0 (09/03/09) — PAGE 101
ENCLOSURE ASSY. #3
NO.
PART NO.
PART NAME
QTY.
REMARKS
1 C5454202603 SPLASHER
PANEL
1
1A C5494405704
LINING
1
2
0019110065
HEX HEAD BOLT
6
2A 0042310000
WASHER,
LOCK
6
2B 0042410000
WASHER,
FLAT
6
3 C5454101703 SIDE
PANEL
1
3A C5494400904
LINING
1
4 C5454101803 SIDE
PANEL
1
4A C5494405004
LINING
1
5 C5454101903 SIDE
PANEL
1
5A C5494405104
LINING
1
6 C5454102003 SIDE
PANEL
1
6A C5494405204
LINING
1
7 C5454001903 SIDE
DOOR
1
7A C5494404504
LINING
1
8 C5454002003 SIDE
DOOR
1
8A C5494404604
LINING
1
9 C5454002103 SIDE
DOOR
1
9A C5494404704
LINING
1
10 C5454002203
SIDE
DOOR
1
10A C5494404804
LINING
1
11 C5454700304
LOUVER
PANEL
2
12 7525151604
LOUVER
PANEL
1
13 C5454700404
LOUVER
PANEL
1
14 7525151304
LOUVER
PANEL
1
15 7525151404
LOUVER
PANEL
1
16 C5454700204
LOUVER
PANEL
1
17 0207106000
HEX
NUT
74
18 C5454301004
DUCT
2
18A C5494405504
LINING
1
18B C5494405804
LINING
1
19 C5454300704
DUCT
1
19A C5494403904
LINING
1
20 C5454301104
DUCT
1
20A C5494405604
LINING
1
