DCA800SSK2 60 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #0 (09/03/09) — PAGE 103
ENCLOSURE ASSY. #3 (CONTINUED)
NO. PART NO. PART NAME QTY. REMARKS
21 C5454300604 DUCT 1
21A C5494405904 LINING 1
22 C5454300904 DUCT 1
22A C5494405904 LINING 1
23 C5454300804 DUCT 1
23A C5494405304 LINING 1
24 C5454300904 DUCT 1
24A C5494405404 LINING 1
25 0019208020 HEX HEAD BOLT 71
26 0825007362 DOOR HANDLE 3
27 0021806016 MACHINE SCREW 12
28 0845046904 HINGE 11
28A 0845045004 WASHER 11
29 0845049004 HINGE 11
29A 0845045004 WASHER 11
30 0019208020 HEX HEAD BOLT 44
31 0845031504 CAP 22
32 0601850097 STOPPER 16
33 0025408025 MACHINE SCREW 22
34 0019110065 HEX HEAD BOLT 8
34A 0042310000 WASHER, LOCK 8
34B 0042410000 WASHER, FLAT 8
35 B9114000002 DOOR HANDLE 4
36 0021806016 MACHINE SCREW 16
37 C5454700104 LOUVER PANEL 1
