Nameplate and decals assy – Multiquip MQ POWER WHISPERWATT SERIES 60HZ GENERATOR (STD.) (KOMATSU SAA6D170E-3 DIESEL ENGINE) DCA800SSK2 User Manual
Page 107
DCA800SSK2 60 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #0 (09/03/09) — PAGE 107
NAMEPLATE AND DECALS ASSY.
NO.
PART NO.
PART NAME
QTY.
REMARKS
12
B9521100404
DECAL : SAFETY INSTRUCTIOS ......................................1 ........... B92110040
13
B1552000103
DECAL : CAUTION ..............................................................2 ........... B15200010
CONTROL PANEL & BOX GROUP
21
0800520100
PLATE : ON OFF ................................................................1 ........... AT 202
22
0800520904
PLATE : AMMETER CHANGE OVER SWITCH ..................1 ........... N2438
23
0800520814
PLATE : VOLTMETER CHANGE OVER SWITCH ...............1 ........... N2439
24
0800564004
PLATE : OFF .......................................................................2 ........... N3805
25
0800565004
PLATE : ON .........................................................................2 ........... N3806
26
0840624504
DECAL : CIRCUIT BREAKER .............................................1 ........... S3031
27
0840624604
DECAL : PANEL LIGHT SWITCH .......................................1 ........... S3032
28
0840624704
DECAL : PILOT LAMP .........................................................1 ........... S3033
29
0840624804
DECAL : VOLTAGE REGULATOR .......................................1 ........... S3034
210
B9531100604
DECAL : WARNING ELECTRIC SHOCK HAZARD ............2 ........... B93110060
211
C5551000303
DECAL : SETTING FOR OUTPUT VOLTAGE .....................1 ........... C55100030
212
C5561101003
DECAL : WHISPERWATT 800 ............................................1 ........... C56110010
ENGINE & RADIATOR GROUP
31
0800689204
DECAL : COOLING WATER ................................................1 ........... S961
32
B9504000304
DECAL : CAUTION HOT PARTS .........................................1 ........... B90400030
33
B9504000404
DECAL : WARNING MOVING PARTS .................................2 ........... B90400040
34
B9504100104
DECAL : WARNING HOT COOLANT ..................................1 ........... B90410010
35 0600501100 DECAL
:
WARNING.............................................................1
........... 0600501100
36
0966810000
DECAL : FUEL PRIMING
1
ENGINE OPERATING PANEL GROUP
51
C5551001203
DECAL : OPERATING PANEL ............................................1 ........... C55100120
51A
0840647804
DECAL : EMERGENCY STOP ............................................1 ........... S4100
52
C5551001104
DECAL : WARNING LAMP ..................................................1 ........... C55100110A
53
C0551000504
DECAL : BATTERY SWITCH ..............................................1 ........... C05100050
OUTPUT
TERMINAL
GROUP
61
0840614104
DECAL : GROUND ..............................................................1 ........... S2635
62
9039209064
DECAL : START CONTACT ................................................1 ........... S4468
63
0840655704
DECAL : TERMINAL COVER STOPPER ............................1 ........... S4516
64 B9511100304
DECAL
:
WARNING.............................................................1
........... B91110030
65
B9511100404
DECAL : WARNING ELECTRIC SHOCK HAZARD ............1 ........... B93110050
66
B9531100504
DECAL : WARNING ELECTRIC SHOCK HAZARD ............1 ........... B93110050
67
C0551000404
DECAL : 3 PHASE OUTPUT TERMINAL ............................1 ........... C05100040
68
C5551000403
DECAL : RECEPTACLE & CIRCUIT BREAKER .................1 ........... C55100040
69
0840619904
DECAL : DANGER HIGH VOLTAGE ....................................1 ........... S2731
