PAGE 12 — DCA800SSK2 60 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #0 (09/03/09)
SPECIFICATIONS
Generator Specifi cations Table 1.
Model DCA800SSK2 (Standard)
Type
Revolving fi eld, self ventilated,
open protected type synchronous generator
Armature Connection Star with Neutral
Phase 3
Standby Output 880 kVA (704 kW)
Prime Output 800 kVA (640 kW)
Voltage - 1 Ø 120, 127, 139, 240, 254, 277V Adjustable
Voltage - 3 Ø 208, 220, 240, 416, 440, 480V Reconnectable
Frequency 60 Hz
Speed 1800 rpm
Power Factor 0.8
Aux. AC Power Single Phase, 60 Hz
Aux. Voltage/Output 4.8 Kw (2.4 kW x 2)
Dry Weight 23,634 lbs. (10,720 kg.)
Wet Weight 25,308 lbs. (11,479 kg.)
Engine Specifi cations Table 2.
Model KOMATSU SAA6D170E3
Type
4 cycle, watercooled, direct injection, turbocharged
airtoair intercooled
No. of Cylinders 6 cylinders
Bore x Stroke 6.69in. x 6.69 in. (170 mm x 170 mm)
Displacement 1413 cu. in. (23,150 cc)
Rated Output 1008 HP/1800 RPM
Starting Electric 24 VDC
Coolant Capacity 40.4 gal. (153 liters)
Lube Oil Capacity 37.2 gal. (141 liters)
Fuel Type #2 Diesel Fuel
Fuel Tank Capacity 129.5 gal. (490 liters)
Fuel Consumption
41.3 gal. (156.5 L)/hr at full load 30.8 gal. (116.4 L)/hr at 75% load
22.6 gal. (85.9 L)/hr at 50% load 14.5 gal. (54.9 L)/hr at 25% load
Battery 12V 200Ah x 4 (24V System)
