DCA800SSK2 60 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #0 (09/03/09) — PAGE 67
ENGINE ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 C5924200134 ENGINE, KOMATSU SAA170E3 1
1-1 0602046653 AIR CLEANER ELEMENT OUTER 2
1-1A 0602046653-1 AIR CLEANER ELEMENT, INNER 2
1-2 6002111231 OIL FILTER CARTRIDGE ...........................2 ................REPLACES P/N 0602041146
1-3 6004111171 CORROSION RESISTOR CARTRIDGE .....1 ................REPLACES P/N 0602045144
1-4 6008711220 DUST SENSOR ..........................................1 ................REPLACES P/N 060204043
1-4A 6240613821 FAN BELT ....................................................1 ................REPLACES P/N 0602015227
2 C5304200504 ENGINE FOOT 2
3 C5304200604 ENGINE FOOT 2
4 0010118070 HEX HEAD BOLT 8
5 0030018000 HEX NUT 8
6 0040018000 WASHER, LOCK 8
7 0041618000 WASHER, FLAT 8
8 0605000012 RUBBER SUSPENSION 4
9 0030020000 HEX NUT 8
10 0040020000 WASHER, LOCK 8
13 6995619380 CUSHION ....................................................2 ................REPLACES P/N 0605000498
14 0010118100 HEX HEAD BOLT 8
15 0030018000 HEX NUT 16
16 0041618000 WASHER, FLAT 16
17 C5311100104 RADIATOR BRACKET 2
18 0017112025 HEX HEAD BOLT 4
19 0017110025 HEX HEAD BOLT 4
20 0199603100 HOSE 1
21 0605515170 HOSE CLIP 1
22 6162637810 RESERVE TANK .........................................1 ................REPLACES P/N 0602010207
23 C2317100503 RESERVE TANK BRACKET 1
24 6212617210 RESERVE TANK .........................................1 ................REPLACES P/N 0602010206
25 C5317100003 RESERVE TANK BRACKET 1
