DCA800SSK2 60 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #0 (09/03/09) — PAGE 17
MAJOR COMPONENTS
Major Components
Figure 3.
Generator Major Components
Table 4.
ITEM NO.
DESCRIPTION
1
Air Filter Assembly
2
Muffl er Assembly
3
Fuel Tank Assembly
4
Engine Operating Panel Assembly
5
Battery Assembly
6
Output Terminal Panel Assembly
7
Generator Assembly
8
Generator Control Panel Assembly
9
Engine Control Panel Assembly
