DCA800SSK2 60 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #0 (09/03/09) — PAGE 81
ENGINE OPERATING PANEL ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 C5484001202 SUPPORT LEG 1
2 0017112045 HEX HEAD BOLT 4
2A 0030012000 HEX NUT 4
2B 0041212000 WASHER, FLAT 4
3 0019210025 HEX HEAD BOLT 2
3A 0205010000 HEX NUT 2
3B 0042412000 WASHER, FLAT 2
4 C5352101303 OPERATING PANEL 1
5 0019208020 HEX HEAD BOLT 4
6 C5352100213 OPERATING PANEL COVER 1
7 0019208020 HEX HEAD BOLT 8
8 0226900460 RUBBER SEAL 1
9 8085182004 RUBBER COVER 1
10 8085183004 RUBBER COVER SET FRAME 1
11 0019206020 HEX HEAD BOLT 6
12 0602101016 BATTERY SWITCH 1
13 7522258304 BATTERY SWITCH BRACKET 2
14 0017106030 HEX HEAD BOLT 4
14A 0207006000 HEX NUT 4
15 0019206015 HEX HEAD BOLT 4
16 0601830710 ENGINE SPEED SWITCH 1
17 K6008153730 PREHEAT INDICATOR ................................1 ................REPLACES P/N 0602102055
18 0601830448 PREHEAT BUTTON 1
19 0601831927 EMERGENCY STOP BUTTON 1
20 0602120095 TACHOMETER 1
21 0602122093 OIL PRESSURE GAUGE 1
22 0601842450 VOLTAGE DIVIDER 1
23 0602123092 WATER TEMPERATURE GAUGE 1
24 0602121080 CHARGING AMMETER 1
25 0602125091 FUEL GAUGE 1
26 0602103090 ALARM LAMP 6
26A 0601810244 BULB, DC28V 6
27 0602122272 OIL PRESSURE UNIT FOR GAUGE 1
28 0602123267 WATER TEMP. UNIT FOR GAUGE 1
28A 0602021109 PACKING 1
