DCA800SSK2 60 HZ GENERATOR • OPERATION AND PARTS MANUAL — REV. #0 (09/03/09) — PAGE 83
OUTPUT TERMINAL ASSY.
NO. PART NO. PART NAME QTY. REMARKS
1 C5231700003 OUTPUT TERMINAL SET BOARD 1
2 7521860504 OUTPUT TERMINAL 4
3 7521850504 OUTPUT TERMINAL BRACKET 4
4 0010112040 HEX HEAD BOLT 8
4A 0030012000 HEX NUT 8
4B 0040012000 WASHER, LOCK 8
4C 0041212000 WASHER, FLAT 16
5 0010112060 HEX HEAD BOLT 8
5A 0030012000 HEX NUT 8
5B 0040012000 WASHER, LOCK 8
5C 0041212000 WASHER, FLAT 16
6 00101112040 HEX HEAD BOLT 24
6A 0030012000 HEX NUT 24
6B 0040012000 WASHER, LOCK 24
6C 0041212000 WASHER, FLAT 48
7 C5234000004 TERMINAL 1
8 0801830904 HEX HEAD BOLT 1
9 0039320000 HEX NUT 2
10 0040020000 WASHER, LOCK 3
11 0041420000 WASHER, FLAT 4
12 0019112050 HEX HEAD BOLT 6
12A 0042312000 WASHER, LOCK 6
12B 0042412000 WASHER, FLAT 6
13 0601850275 GROMMET 1
14 0601815324 TERMINAL BOARD 1
15 0027104020 MACHINE SCREW 2
16 C4237101304 OUTPUT TERMINAL COVER 1
17 7971867114 RUBBER SHEET 1
18 7521865804 RUBBER SHEET SET PLATE 1
19 0019206020 HEX HEAD BOLT 5
20 0605010660 KNOB 2
21 0207006000 HEX NUT 2
22 0019212040 HEX HEAD BOLT 4
23 0041212000 WASHER, FLAT 4
24 0805009804 RUBBER STAY 4
25 0030012000 HEX NUT 4
26 7521865603 STOPPER 1
27 0010108030 HEX HEAD BOLT 1
27A 0030008000 HEX NUT 1
27B 0041208000 WASHER, FLAT 2
28 C4237100504 COVER 1
29 0017108020 HEX HEAD BOLT 5
30 0601808804 CIRCUIT BREAKER, 50A 3
