1. FUNCTIONS AND CONFIGURATION
(2) Model
MR–J2S–100CL or less MR–J2S–200CL 350CL
Program compatibility operation function
Rated output
Rating plate
Rating plate
MR–J2S–
Series
CL
Note:1. Not supplied to the servo amplifier of
MR-J2S-60CL or more.
2. Not supplied to the servo amplifier of
MR-J2S-100CL or more.
Power Supply
Power supply
None
3-phase 200 to 230VAC
(Note2)
1-phase 230VAC
(Note1)
1
1-phase 100V to 120VAC
Symbol
Rated
output [W]
100 10
Symbol
200 20
400 40
600 60
750 70
1000 100
2000 200
3500 350
Rated
output [W]
Symbol
5000 500
7000 700
MR-J2S-500CL MR-J2S-700CL
Rating plate Rating plate
1.5 Combination with servo motor
The following table lists combinations of servo amplifiers and servo motors. The same combinations apply
to the models with electromagnetic brakes and the models with reduction gears.
Servo motors
HC-SFS HC-UFS Servo amplifier
HC-KFS HC-MFS
1000r/min 2000r/min 3000r/min
HC-RFS
2000r/min 3000r/min
MR-J2S-10CL (1) 053 13 053 13 13
MR-J2S-20CL (1) 23 23 23
MR-J2S-40CL (1) 43 43 43
MR-J2S-60CL 52 53
MR-J2S-70CL 73 73 72 73
MR-J2S-100CL 81 102 103
MR-J2S-200CL 121 201 152 202 153 203 103 153 152
MR-J2S-350CL 301 352 353 203 202
MR-J2S-500CL 502 353 503 352 502
MR-J2S-700CL 702
Servo motors
HA-LFS
Servo amplifier
(Note)
1000r/min
(Note)
1500r/min
2000r/min
(Note)
HC-LFS
MR-J2S-60CL 52
MR-J2S-100CL 102
MR-J2S-200CL 152
MR-J2S-350CL 202
MR-J2S-500CL
(Note)
502 302
MR-J2S-700CL 601 701M (Note) 702
Note: Consult us since the servo amplifier to be used with any of these servo motors is optional.
