14 - 25
14. OPTIONS AND AUXILIARY EQUIPMENT
(3) Outline drawing
2- 5.3(0.21)(mounting hole)
3(0.12)
41.5(1.63)
75(2.
95)
88(3.47)
100(3.94)
MR-J2CN3TM
CN3A CN3B CN3C
A1
B1
A6
B6
TE1
[Unit: mm]
([Unit: in])
Weight: 110g(0.24Ib)
(4) Bus cable (MR-J2HBUS M)
10120-6000EL (connector)
10320-3210-000 (shell kit)
MR-J2HBUS05M
MR-J2HBUS1M
MR-J2HBUS5M
1
11
2
12
3
13
4
14
5
15
6
16
7
17
8
18
9
19
10
20
1
11
2
12
3
13
4
14
5
15
6
16
7
17
8
18
9
19
10
20
10120-6000EL (connector)
10320-3210-000 (shell kit)
Plate Plate
05
1
5
0.5 (1.64)
1 (3.28)
5 (16.4)
Symbol Cable length [m(ft)]
Model: MR-J2HBUS M
