1. FUNCTIONS AND CONFIGURATION

(2) MR-J2S-200CL MR-J2S-350CL

Options and auxiliary equipment

No-fuse breaker

Magnetic contactor

Servo configuration software

Regenerative brake option

Reference

Section 14.2.2

Section 14.2.2

Chapter 6

Section 14.1.1

Options and auxiliary equipment

Reference

Cables

Manual pulse generator

External digital display

Section 14.2.1

Section 14.1.8

Section 14.1.7

Power
factor
improving
reactor
(FR-BAL)

3-phase 200V
to 230VAC
power supply

No-fuse
breaker
(NFB) or
fuse

Magnetic
contactor
(MC)

To CN2

To CN3

To CN1B

To CN1A

L

1

L

2

L

3

L

21

L

11

Servo amplifier

Regenerative brake option

P

C

U

V W

Personal
computer

Servo
configuration
software
MRZJW3-
SETUP151E

Power factor improving reactor Section 14.2.3

Junction terminal
block

Manual pulse
generator

External digital display

Command device
