12 - 3
12. OUTLINE DIMENSION DRAWINGS
(3) MR-J2S-200CL MR-J2S-350CL
MITSUBISHI MITSUBISHI
70(2.76) 195(7.68) 90(3.54)
78(3.07)
6
1
6
8(
6
.61)
1
5
6(
6
.14)
6
6 ( 0.24)
mounting hole
Terminal layout
TE1
[Unit: mm]
([Unit: in])
TE2
PE terminal
(0.24)
(0
.24)
Fan air orientation
Servo amplifier
Weight
[kg] ([lb])
MR-J2S-200CL
MR-J2S-350CL
2.0 (4.41)
TE1
L 1 L 2 L 3 U V W
L 11 L 21 D P C N
Terminal screw: M4
Tightening torque: 1.2 [N m] (175.6 [oz in])
Terminal screw: M4
Tightening torque: 1.2 [N m] (175.6 [oz in])
TE2
PE terminals
Terminal screw: M4
Tightening torque: 1.2 [N m] (175.6 [oz in])
