MK CX-3 Revision 09/04, Effective Date September 17, 2004 Page 8
UNPACKING, TRANSPORT and ASSEMBLY
UNPACKING:
Your MK CX-3 has been shipped from the factory thoroughly inspected. Only minimal assembly is required.
If not already done, remove the MK CX-3 from the pallet and place it on a flat surface (lift the Concrete Saw
using the lifting points shown below.
CONTENTS:
In the containers, you will find one (1) MK CX-3, one (1) Diamond Blade, two (2) Blade Shaft Wrenches, one
(1) Handlebar, two (2) Handlebar Tri-knobs, two (2) Tri-Knob Washers, one (1) Ball Knob, one (1) Shoulder
Bolt, one (1) Pointer Arm, one (1) Pointer Wheel, one (1) Pointer, one (1) CX-3 Owners Manual, one (1)
Robin’s or Honda’s Engine Owners Manual and one (1) warranty card.
MK CX-3 Diamond
Blade
2 Blade Shaft
Wrench
Handlebar Handlebar
Tri-Knob
Tri-Knob
Washer
Ball Knob &
Shoulder Bolt
Pointer Arm Pointer Wheel Pointer
CX-3
Owners Manual
Robin or Honda
Owner’s Manual
Warranty
Card
