MK CX-3 Revision 09/04, Effective Date September 17, 2004 Page 7
SAFETY
CX-3 SPECIFIC WARNINGS:
Read Owners Manual
Wear Protective Gear for –
Lungs Ear Eye
PRODUCT SPECIFICATIONS:
The MK CX-3 is a versatile Concrete Saw. Operated and used according to this manual, the MK CX-3 will
provide years of dependable service.
General Description:
The MK CX – 3 is engineered as a portable concrete saw powered by a 6 horsepower, Robin gas engine or a
6.5 horsepower Honda gas engine. The saw is capable of cutting up to five (5) inches in depth.
Motor and Weight Specifications:
Motor and Weight specifications for the MK CX-3 are listed in Table 2 below.
Motor Type 4-stroke, Overhead valve, single cylinder
Max Power Output 6 / 6.5 Hp
Max RPM 3600 RPM
Blade Speed 3400 to 3600 RPM (Depending on Blade Diameter)
Fuel Tank Capacity 2.7 Liters
Engine Oil Capacity 0.6 Liters
Weight Approximately 185 lbs.
Table 2
Blade:
The MK CX-3 uses a 12 to 14 inch diameter diamond blade.
Concrete Saw Usage:
The MK CX-3 is designed to cut various grades of concrete surfaces.
Features:
• Conveniently placed engine controls for ease of usage
• Height adjusting screw designed to accurately adjust the depth of the cut
• Ergonomically designed handlebar to reduce operator fatigue
• Poly micro V-belt to ensure maximum power transfer from the engine to the blade.
