MK Diamond Products MK CX-3 - Manual (Page 18)

MK CX-3 Revision 09/04, Effective Date September 17, 2004 Page 18
SETUP, STARTUP, ADJUSTMENT, OPERATION and SHUTDOWN
(P)
Close Cooling Supply Valve
(O)
When the Cut is Complete, Raise
the Blade
(K)
Verify proper cooling flow and
adjust the water flow on the blade
to a desired amount
(I)
With the engine running adjust
the throttle approximately half
way
(J)
Open Cooling Supply Valve
Direction of
Movement
Throttle Lever
(L)
Adjust the throttle as needed to
make the cut
Direction of
Movement
Throttle Lever
(N)
Perform the cut using only enough
pressure to follow the original
marked line. Do not attempt to
steer the saw
(M)
Slowly lower the Blade until the
desired level is reached and begin
the cut
Cooling
Supply Valve
Direction
to Open
Verify
Flow
Blade
Lowered
Rotate Counter-
clockwise to Lower
Perform
Cut
Direction
of Cut
Blade
Raised
Rotate
clockwise
to raise
Cooling
Supply Valve
Direction
to Open
