MK CX-3 Revision 09/04, Effective Date September 17, 2004 Page 40
EXPLODED VIEW AND PARTS LIST
J Assembly, Depth Control 1 N/a
J1 Wheel, Depth Control 1 155156
J2 Screw, 3/8-16 X 1/2 Socket Head Set 1 153710
J3 Knob, Ball, 2”, 3/8-16 Insert 1 158519
J5 Screw, 1/2 X 3/4 Socket Head Shoulder, w/ 3/8-16 X 5/8 Thread 1 156177
J6 Tube, Depth Control ¾-10 1 159098
J7 Nut, 3/8-16 Nylock Hex 1 152505
J8 Screw, 3/8-16 X 2 Hex Head Cap 1 153485
J9 Bearing, Flange, FHSLF 204-12G 1 155151
J10 Screw, 3/8-16 X 1 ½ Hex Head Cap 2 153528
J11 Washer, 3/8 SAE Flat 2 151915
J12 Nut, 3/8-16 Nylock Hex 2 152505
J13 Screw, Depth Control 1 155062
J14 Nut, 3/4-10 Hex 2 155063
J15 Spring, Detent 1 156609
K Assembly, Handlebar 1 n/a
K1 Handlebar 1 158849
K2 Grip, Handle 2 229413
K3 Tri-Knob, 3/8-16 X 2 2 156770-04
K4 Washer, 3/8 SAE Flat 4 150923
L Assembly, Pointer 1 155568
L1 Arm, Pointer 1 155056
L2 Pointer 1 155057
L3 Wheel, Pointer, w/ 3/8 X 1/2 X 1 5/8 nylon bushing 1 155066
L4 Screw, 1/4-20 X 3/4 Thumb 2 150991
L5 Nut, 3/8-16 Nylock Hex 3 152505
L6 Washer, 3/8 SAE Flat 1 150923
L7 Clip, Stop 1 157837
M Assembly, Water Valve 1 155458
M1 Bracket, Water Valve 1 158833
M1A Bracket, Water Valve 1 158833-OR
M2 Screw, ¼-20 x ½ Hex Head Cap 2 152608
M3 Washer, ¼ Split Lock 2 152591
M4 Fitting, Brass, 1/2 MNPT X Garden Hose Swivel 1 151322
M5 Valve, Ball, Shut-Off, 1/2 FNPT X 1/2 FNPT 1 150843
M6 Nut, 1/2 NPT 1 152729
M7 Fitting, Brass, 1/2 MNPT X 3/8 BARB 1 153653
M8 Clamp, 5/8 Hose 2 151198
M9 Hose, 3/8 ID Vinyl 30” 150845
N Assembly, Throttle, Honda 1 n/a
N1 Screw, 10-24 X 1/2 Pan Head Phillips Cap 2 151744
N2 Washer, #10 SAE Flat 2 154369
N3 Nut, 10-24 Clip 2 155407
N4 Assembly, Throttle Control 1 155406
N5 Cable, Throttle, CX3 Honda 1 159479
NA Assembly, Throttle, Robin 1 n/a
NA1 Screw, 10-24 X 1/2 Pan Head Phillips Cap 2 151744
NA2 Washer, #10 SAE Flat 2 154369
