MK CX-3 Revision 09/04, Effective Date September 17, 2004 Page 38
EXPLODED VIEW AND PARTS LIST
PARTS LIST:
Item Description Qty MK p/n
A Assembly, Frame 1 n/a
A1 Casting, Frame, Right 1 159257
A2 Casting, Frame, Left 1 159259
A3 Support, Horizontal Frame 3 158857
A4 Connector, Tube
∅1 3/8 x 5/16-18 6 159206
A5 Screw, 5/16-18 x 1 ½ Hex Hd. Cap 6 152467
A6 Washer, 5/16 SAE Flat 6 151754
A7 Washer, 5/16 Split Lock 6 151747
A8 Wheel, Front, 4 X 1 ½ 2 150830
A9 Shim, ¾ x 1 ¼ x .045 6 153699
A10 Axle, Front 1 158862
A11 Bushing, Flange 2 159207
A12 Wheel, Rear, 8 X 2 ¼ 2 155986
A13 Pin, Cotter 1/8 x 1.0 4 156613
A14 Collar, Set ¾ 4 153814
B Assembly, Console 1 n/a
B1 Console, Frame 1 158828
B2 Screw, 5/16-18 x 1 ½, Hex Head Cap 4 152467
B3 Washer, 5/16 SAE Flat 4 151754
B4 Washer, 5/16 Split Lock 4 151747
B5 Nut, 5/16 Hex 4 101196
B6 Label, Console 1 159208
C Assembly, Truck 1 n/a
C1 Truck, Weldment 1 159260
C2 Plate, Serial Number 1 157918
C3 Label, CX3 1 159482
C4 Tag, Serial Number, Blank 1 157500
D Assembly, Blade Shaft 1 n/a
D1 Shaft, Blade, 1 158879
D2 Screw, Blade Shaft, ½-13 x 1 Hex Head, Left Hand Thread, Grade 5 1 159203
D3 Screw, Blade Shaft, ½-13 x 1 Hex Head, Right Hand Thread, Grade 5 1 159204
D4 Flange, Inner 1 158880
D5 Flange, Outer 1 158881
D6 Pulley, Polly-V 2 ½ x 1 x J16 1 158470
D7 Bearing, 1” Pillow Block 2 155072
D8 Screw, 3/8-16 X 1 1/2 Hex Head Cap 4 153528
D9 Washer, 3/8 Split Lock 4 150925
D10 Washer, 3/8 SAE Flat 8 101360
D11 Nut, 3/8-16 Hex 4 101188
E Assembly, Shaft Cover 1 n/a
E1 Casting, Cover, Shaft 1 158843
E2 Screw, 5/16-18 X 1 Hex Head Cap 3 151743
E3 Washer, 5/16 Split Lock 3 151747
E4 Washer, 5/16 SAE Flat 3 151754
