GarrettCom 6K32 User Manual
Page 9
Magnum 6K32 Managed Switch Installation and User Guide (02/05)
3
www GarrettCom com
.
.
Alarm Contact (Optional)
Alarm Contact option is offered as a special order. The alarms can be configured
through two normally closed Form-C contacts, one for loss of power and one
software alarm through user selectable software traps.
Manual switches for modular slot port module only
The copper daughter board has an internal switch for selecting MDI-MDIX
crossover on port # 1, located next to the port internally.
Note: Other port-specific user settings ( such as FDX or HDX,AUTO OFF,
copper 10/100 speed) can be configured using software commands.
Agency
Approvals
UL listed (UL1950), cUL, CE, Emissions meet FCC Part 15 Class A
NEBS L3 and ETSI Compliant for Carrier Central Offices
IEEE P1613 Environmental Standard for Electric Power Substations.
IEC61850 EMC and Operating Conditions Class C for Power Substations
Warranty:
Three years, return to factory
Made in USA
For a Configuration Guide, see the GarrettCom web site at
http://www.garrettcom.com/techsupport/insertion_guides/6k32cg.pdf
for additional details.
