Magnum 6K32 Managed Switch Installation and User Guide (02/05)
5
www GarrettCom com
.
.
6KP8-45-2MT
“6+2” module, w/six RJ-45 ports and two 2km mm MTRJ connectors
6KP8-45-2SLC “6+2” module, w/six RJ-45 ports and two 100Mb 15km sgl. mode FX
LC connectors
Gigabit Transceiver options
6KP5V-G4RJ
“G+2” module, with one GBIC transceiver and four 10/100 RJ-45
connectors
6KP3V-G2SC
“G+2” module, with one GBIC transceiver and two 100Mb 2km FX SC
fiber ports connectors
GBPM-2OTX
Two port Gigabit module provides two GBIC open transceiver ports for
a user-selectable GBIC transceiver module
GBPM-COTX
One slot Gigabit 6K module provides one GBIC open transceiver port
for a user-selectable GBIC transceiver module
GBIC-SXSC
GBIC transceiver module for use in GBPM-xOTX. One 1000BASE-SX
port with multimode SC fiber connector
GBIC-LXSC10 GBIC transceiver module for use in GBPM-xOTX. One 1000BASE-
LX/LH port with 1310nm single mode SC(10km) fiber connector
GBIC-LXSC25 GBIC transceiver module for use in GBPM-xOTX. One 1000BASE-
LX/LH port with 1310nm single mode SC(25km) fiber connector
GBIC-LXSC40 GBIC transceiver module for use in GBPM-xOTX. One 1000BASE-ZX
port with 1550nm, single mode SC(40km) fiber connector
GBIC-LXSC70 GBIC transceiver module for use in GBPM-xOTX. One 1000BASE-ZX
port with 1550nm, single. mode SC(70km) fiber connector.
GBIC-TP
GBIC transceiver module for use in GBPM-xOTX. One 802.3ab
1000BASE-T port with RJ-45 connector
6KM-BLNK
Blank cover for one 6K32 module slot opening in a Magnum 6K32 or
6K32R chassis
CONSOLE CBL Industry standard serial cable, DB-9 connectors for RS-232 “ null-
modem “ connection (sometimes called an Xmodem cable), used to connect a PC or a
character terminal to the Management port.
CONSOLE USB Console attachment cable, serial to USB, cable with one DB9 for the
managed Switch and a USB interface for the USB connector to a PC.
See also the “Configuration Guide” for the 6K32 on the GarrettCom web site at
http://www.garrettcom.com/techsupport/insertion_guides/6k32cg.pdf.
GarrettCom, Inc. reserves the right to change specifications, performance
characteristics and/or model offerings without notice.
