BX900 S1 Operating Manual 61
Installation and operation
5.1.1.1 Control elements
5.1.1.2 LEDs on the control panel
On/Off button
When the system is switched off, it can be switched on again by
pressing the On/Off button.
When the system is operating, pressing the On/Off button will
switch off the system.
V
CAUTION!
Risk of loss of data!
I
The On/Off button does not disconnect the server from the
mains voltage. To disconnect from the mains completely,
remove the power plug(s).
ID ID button
Lights up (blue) on the front and on the rear of the system unit when
the ID button is pressed. The two ID indicators are synchronized.
Navigation buttons for the LocalView menu system
With the buttons , , and you select a function. Pressing
the button executes the selected function.
Power indicator (two-color)
Lights up green when the system unit is switched on.
Lights up orange when the system unit is switched OFF, but mains
voltage is present (standby mode).
OK
