EQUIPMENT LISTS
Standard supply
Name Type
Code
No.
Qty
Remarks
Control Unit
FSV-3001
—
1
With cable
FSV-3002 — For
FSV-30
Processor Unit
FSV-3002S —
1
For FSV-30S
Transceiver Unit
FSV-301
—
1
FSV-303/303-R
—
1200 mm stroke
Hull Unit
FSV-304/304-R
—
1
1600 mm stroke
CP10-06000 000-144-389
1
set
Signal cable 10S2078
(between transceiver unit and
hull unit, 8 m)
CP10-06201 007-008-540
1
set
For transceiver unit. See
packing list.
Installation Materials
CP10-06100 000-067-067
1 set
For processor unit
CP10-04502, CP10-04506.
See packing list.
SP10-03101 007-008-530
1
set
For transceiver unit. See
packing list.
SP10-02601 006-921-340
1
set
For processor unit. See
packing list.
Spare Parts
SP10-02603
006-921-360
1 set
For processor unit
FP10-02901
007-008-780
1 set
For processor unit
Accessories
FP10-02201
006-922-390
1 set
For control unit
Optional Equipment
Name Type
Code
No.
Qty
Remarks
Control Unit
FSV-3001
—
1
37-core Cable
10S1258
001-113-000-10
1 Specify
length
E/S Interface
VI-1100A
—
1
Net Sonde
Junction Box
CS-170 —
1
Power Supply Kit
FSV-2403
000-067-013
1
For connection of CS-120A
MJ-A6SPF0012-100C 000-154-037-10
1
10 m, NMEA, 6P-6P
NMEA Cable
MJ-A6SPF0012-050C 000-154-053-10
1
5 m, NMEA, 6P-6P
8-core Cable
VVS 0.3
×8C *6M*
000-555-043
1
6 m, for echosounder, 02S8040
Attachment
Flange
OP10-27 000-067-050
1
Attachment Kit
OP10-24
006-943-530
Loudspeaker SEM-21Q
000-144-917
1
Installation
Materials
CP10-04801 006-934-240
1
See back of manual for details.
FSV-305-5 000-067-072 Junction box, 10S2240, 10S2144
Cable Extension
Kit
FSV-305-15 000-067-073
1
Junction box, 10S2240, 10S2145
Data Recording
Kit
OP10-31 000-017-095
1
OP10-33 000-017-096
1
φ38.1
Calibration Ball
OP10-34 000-017-097
1
φ47.625
