2-12
2.4.2 Fabrication of power cable type DPYCYS-2.5 (TB-B101)
Fabricate the cable DPYCYS-2.5 as below for connection to the power source.
Conductor
S = 4 mm
∅ = 2.55 mm
2
Vinyl
sheath
Armor
Cable DPYCYS-2.5
140
35
30
FV2-4 (2 pcs)
Vinyl sheath Amor Anticorrosive
sheath
Fabrication of cable type DPYCYS-2.5
2.4.3 Hull control cable (10S2078)
Connect the hull control cable (10S2078) to the CN-B102 in the transceiver unit.
Note: The same type of connector is fitted at each end, however the connector which has a
larger portion of its sheath removed should be connected to the transceiver unit.
