Furuno FSV-30S - Manual (Page 22)

1-16
Spring washer
Spring washer
Flat washer
O-ring
Flat washer
Insulation gasket (2)
Insulation gasket
Hex. bolt
Hex. nut
Retraction tank
Stern side
(Seven locations) Bow side
(17 locations)
O-ring
Hex. bolt
Flat washer
Flange of hull unit
O-ring
Insulation gasket (1)
Insulation gasket (2)
Spring washer
Flat washer
Hex. nut
Flat washer
Flange of hull unit
O-ring
Insulation gasket (1)
Insulation gasket (2)
Spring washer
Hex. nut
Installation of attachment kit
