2-3
10S2223
14.6 m
0.6 m
14.0 m
Transceiver unit side
Hull unit side 10S2078
8 m
0.38 m
7.2 m
0.28 m
0.07 m
0.07 m
Raise/lower control box
of the hull unit side
Clamp point
Clamp point
P2
(40 pin)
P1
(34 pin)
Clamp point .
Note that the amount of cable inside the cable clamp on the cable between the hull unit and
transceiver unit may be shorted depending on cable length.
