iii
SYSTEM CONFIGURATION
Note 1: Power Kit FSV-2403 (option, installed in
processor unit) required to connect CS-120A.
TRANSCEIVER
UNIT
FSV-301
100/110/115/
220/230 VAC,
1
φ,
50/60 Hz
220 VAC,
3
φ,
50/60 Hz
PROCESSOR UNIT
FSV-3002/3002S
Loudspeaker
Sub Monitor
Echo Sounder,
Current Indicator,
other
Navigator 1
Navigator 2
AD Converter
AD-10
Current
Indicator
Current
Indicator/Log
E/S Interface
VI-1100A
Net Recorder
VI-1100A
Net Sonde
Junction Box
CS-170 VI-1100A
Net Sonde
External
Interface CS-120A
(Note 1)
100/110/115/
220/230 VAC,
1
φ,
50/60 Hz
CONTROL UNIT
FSV-3001
Hull unit Specifications
FSV-303
FSV-303-R
1200 mm stroke
FSV-304
FSV-304-R 1600 mm stroke
HULL UNIT
Gyrocompass
Cable for
Extension Kit
FSV-305-5 or
FSV-305-15
(incl. Junction
Box)
VGA Monitor
Standard
Local Supply
Option
