1-14
1.7 Cable Extension Kit (option)
For extension of the transducer cable between the hull unit and the transceiver unit, use the
cable extension kit (option), which includes a junction box. The kit is available in 5 m or 15
m extension lengths. Below are the contents of each kit.
Name: Cable Extension Kit, Type: FSV-305-5, Code No.: 000-067-072
Name Type Code No. Qty Remarks
Junction box FSV-305 000-067-032 1
10S2240 000-148-369-03 1 5 m
Cable assembly
10S2144 000-145-360 1 12.9 m
Name: Cable Extension Kit, Type: FSV-305-15, Code No.: 000-067-073
Name Type Code No. Qty Remarks
Junction box FSV-305 000-067-032 1
10S2240 000-148-370-03 1 15 m
Cable assembly
10S2145 000-145-361 1 22.9 m
Fasten the junction box to a bulkhead with 4 bolts (M6, local supply).
Junction box
