1-5
Button / LED Function
LED Function
Lights to indicate the power is on.
Lights when the image scanner becomes ready to read a document in the manual mode and manual start mode.
This indicator turns off when the Start button is pressed to read a document.
Lights when an equipment error occurs. An error messages is displayed on the LCD screen. This indicator blinks
when a document is jammed in the ADF. This indicator turns off when the jammed documents are removed from
the ADF and the upper transport unit is closed.
Button name Function
When the Ready lamp is lit in the manual start mode, pressing this button starts a scanning operation.
When pressed during scanning:
The scanning operation immediately stops and the document under transport is ejected to the stacker.
A picked document, if any, is ejected to the stacker.
The hopper table is lowered to the bottom.
When pressed while waiting for Hopper-timer:
The hopper table is lowered to the bottom.
When pressed displaying the initial screen:
The abrasion counter is displayed.
When pressed occuring the temporary error:
The temporary error is recovered.
When pressed while setting the scanning mode:
The display returns to the initial screen.
Toggles the LCD screen between simplex and duplex reading mode.
Sets the document size.
Sets the scanning density.
Sets the scanning resolution.
Sets the manual mode.
Pressing this button lifts the hopper table to the level for manual mode. Pressing the button again releases the
mode and lowers the hopper table to the bottom.
Toggles the LCD screen between front-side and back-side reading mode.
Toggles the document scanning direction between the portrait and landscape mode.
Sets whether to execute halftone processing (dither or error diffusion) and also sets automatic separation
processing (dither or error diffusion if the image processing option is installed).
Toggles the document scanning mode between the photo and linedrawing mode.
Activates the setup mode. (See Chapter7)
Activates the maintenance mode.
Start
Stop
Duplex
Size
Density
Resolution
Manual
Front/Back
Landscape
Half tone
Document
Mode 1
Mode 2
Power
Check
Ready
