Operator panel(m3099ex/eh), Operator panel(m3099ex/eh) -4, Operator panel (m3099ex – FUJITSU M3099GH User Manual
Page 17: Arrangement
1-4
Arrangement
Operator panel
The operator panel is located at the upper right hand side of the scanner. The panel consists of an
LCD (24 character x 2 line), LEDs and buttons.
Operator Panel(M3099EX/EH)
Power
Ready
Check
Duplex
Size
Density
Resolution
Manual
Front/
Back
Landscape
Half tone
Document
Mode 1
Mode 2
Start
Stop
LCD
24 character x 2 line
03-Chap. (1)
98.2.20, 10:48 AM
4
