HP OmniBook XE3 Removal and Replacement 2-27
Removing the Heatsink Assembly (with Fan)
(HP Authorized Service Providers Only)
Required Equipment
•
Small Phillips screwdriver.
Removal Procedure
1. Unplug the AC adapter, if present, and remove the battery.
2. Remove these additional assemblies:
•
Keyboard cover (page 2-9).
•
Keyboard (page 2-11).
•
Display assembly (page 2-17).
•
Top case (page 2-19).
•
Hinge saddle set (page 2-22).
3. Disconnect the fan cable from the motherboard.
4. Remove all four retaining screws (their springs are attached to them).
5. Lift the heatsink out of the notebook.
