HP OmniBook XE3 Removal and Replacement 2-7
Removing the Mini-PCI PCA
(User-Replaceable)
Certain notebook models include a mini-PCI PCA that contains either a modem or modem/LAN. See
Table 4-2 on page 4-5 for a listing of replacement PCAs and part numbers.
Caution
Provide proper grounding and handle the PCA only by its edges, or you could damage it through
electrostatic discharge.
Required Equipment
•
Small Phillips screwdriver.
Removal Procedure
1. Unplug the AC adapter, if present, and remove the battery.
2. Loosen the screw holding the mini-PCI cover (the cover retains the screw), and remove the cover.
3. Press outward to release the latches at the sides of the PCA, so that its free edge pops up.
4. Disconnect the cable (modem models only) or cables (modem/LAN models only) from the PCA.
5. Gently pull the PCA out of its connector.
