RECON Water Heaters Installation, Operation & Maintenance Manual
CHAPTER 3 – OPERATION
Page 54 of 178 AERCO International, Inc.  100 Oritani Dr.  Blauvelt, NY 10913 OMM-0103_0A
PRI: 10/28/2014 Phone: 800-526-0288 GF-147
3.10 START/STOP LEVELS
The start and stop levels are the Air/Fuel Valve positions (% open) that start and stop the unit,
based on load. These levels are Factory preset as follows:
Start Level Stop Level
RECON 500 28% 16%
RECON 1000 25% 20%
Normally, these settings should not require adjustment.
Note that the energy input is not linearly related to the Air/Fuel Valve position. Refer to Table 3-
7 for the relationship between the energy input and Air/Fuel Valve position for a unit running on
natural gas.
Table 3-7: Relationship between Air/Fuel Valve Position and Energy Input
For Units Running Natural Gas
Air/Fuel Valve
Position (%
Open)
RECON Water Heater Model: Energy Input
(BTU/Hr.)
RECON 500 RECON 1000
16% 50,000 Not Applicable
20% Not Applicable 100,000
30% 116,100 188,000
40% 204,000 334,000
50% 268,700 485,000
60% 320,600 590,000
70% 367,200 693,000
80% 409,400 806,000
90% 448,500 954,000
100% 500,000 1,000,000
