RECON Water Heaters Installation, Operation & Maintenance Manual
CHAPTER 7 – TROUBLESHOOTING GUIDE
OMM-0103_0A
AERCO International, Inc.
100 Oritani Dr. Blauvelt, NY 10913
Page 113 of 178
GF-147
Phone: 800-526-0288 PRI:
10/28/2014
Figure 7-1: Gas Train Component Locations (RECON 1000 Shown)
Figure 7-2: Blower-Side Intake Manifold with Igniter-Injector & Flame Detector
LOW GAS
PRESSURE
SWITCH
HIGH GAS
PRESSURE
SWITCH
MANUAL
SHUTOFF
VALVE
TO AIR/FUEL
VALVE
LEAK
DETECTION
BALL VALVE
GAS INLET
SSOV
LEAK
DETECTION
BALL VALVE
FLAME
DETECTOR
TERMINAL
INTAKE
MANIFOLD
IGNITER TERMINAL
IGNITION ASSEMBLY
SOLINOID VALVE
OBSERVATION PORT
GAS INJECTOR TUBE
COMPRESSION ELBOW & NUT
FLAME
DETECTOR
GASKET
FLEX GAS
HOSE NIPPLE
FLAME DETECTOR MOUNTING STAND-OFFS
CLOCKING WASHERS (1 TO 3 EA.)
