Item Quantity Part name
Pump Material (3196,
HT 3196, CV 3196,
3796)
Pump Material (NM
3196)
Pump Material
(3198)
All Titanium
Vinylester
D.I./Teflon
241
1
Frame Foot
1001
248
1
Oil Thrower
2210
250
1
Gland—Mechanical Seal
Material varies
253B 1
Bearing Clamp Ring
2210
319
1
Sight Glass
Glass/steel
332A 1
Outboard Labyrinth Seal w/O-rings
Brass ASTM B505-96
333A 1
Inboard Labyrinth Seal w/O-rings
Brass ASTM B505-96
351
1
Casing Gasket
Aramid fiber w/EPDM
353
4
Gland Stud
2156
2229
2229
355
4
Gland Stud Nut
2156
2229
2229
358
1
Plug—Casing Drain
2156
–
–
358Y 1 ***
Plug, Impeller
2156
–
–
360C 1 ***
Gasket—Thrust End Cover
Buna
360D 1
Gasket—Frame-to-Adapter
Buna
360Q 1
Gasket—Gland-to-Stuffing Box
Cover
Material varies
361A 1
Retaining Ring
Steel
370
****
Bolt—Adapter to Case
2228
370B 4
Bolt—Frame-to-Adapter
2210
370C **
Clamp Bolt —Bearing Housing
2210
370D **l
Jack Bolt—Bearing Housing
2210
370F 2
Bolt—Frame Foot to Frame
2210
370H 2
Stud—Stuffing Box Cover-to-Adapter 2228
370Y 2
Bolt—Cap Casing to Support
–
–
–
371C 6 ***
Cap Screw-End Cover to Bearing
Housing
2210
382
1
Bearing Lockwasher
Steel
383
1
Mechanical Seal
Material varies
400
1
Coupling Key
2210
408A 1
Plug—Oil Drane
2210
408H 4
Plug—Oil Mist Connection
2210
408J
1
Plug—Oiler
2210
408L 1
Plug—Oil Cooler Inlet
2210
408M 1
Plug—Oil Cooler Outlet
2210
408N 1
Plug—Sight Glass
2210
412A 1
O-Ring, Graphoil Impeller
–
–
–
418
3
Jack Bolt—Adapter-to-Case
2228
423
3
Jam Nut—Bearing Housing Jack Bolt 2210
423B 2
Hex Nut—Stuffing Box Cover to
Adapter
2228
