Location Frame 3196, CV 3196, LF
3196, 3796
NM 3196 3198
Lube Dry Lube Dry Lube Dry
Frame-to-adapter bolts All 20 (27) 30 (40) 20 (27) 30 (40) 20 (27) 30 (40)
Bearing-clamp ring
bolts (236A) - duplex
bearing only
STi, MTi 10* (1.1) 17* (1.9) 10* (1.1) 17* (1.9) 10* (1.1) 17* (1.9)
LTi 55* (6.2) 83* (9.4) 55* (6.2) 83* (9.4) 55* (6.2) 83* (9.4)
Bearing end cover bolts
(371C)
XLT-i, i17 9 (12) 12 (16) N/A N/A N/A N/A
Dynamic seal capscrews
(265)
STi, MTi,
LTi
55* (6.2) 83* (9.4) N/A N/A N/A N/A
XLT-i, i17 9 (12) 12 (16) N/A N/A N/A N/A
* Values are in lb-in.
(Nm)
This table provides the maximum torque values for casing bolts.
Table 19: Maximum torque values in lb-ft (Nm) for casing bolts
Models 3196, CV 3196 LF 3196, 3796 with 150 lb
(68 kg) casing flanges
Model HT 3196 and all
models with 300 lb (136
kg) casing flanges
Material specification
Ductile iron casing
with A307 Grade B
casing bolts
Alloy casing with
(304SS) F593 Grade 1 or
(316SS F593) Grade 2
casing bolts
Ductile iron and alloy
casings with A193
grade B7 casing bolts
Frame Casing bolt
diameter
(in.)
Lube Dry Lube Dry Lube Dry
8 in. STi 0.50 20 (27) 30 (41) 35 (47) 54 (73) 58 (79) 87 (118)
6 in. STi 0.625 39 (53) 59 (80) 71 (96) 107 (145) 115 (156) 173 (235)
MTi 0.625 39 (53) 59 (80) 71 (96) 107 (145) 115 (156) 173 (235)
LTi 0.625 39 (53) 59 (80) 71 (96) 107 (145) 115 (156) 173 (235)
XLT-i 0.625 39 (53) 59 (80) 71 (96) 107 (145) 115 (156) 173 (235)
Shaft-end play
Use this table as a reference for shaft-end play values.
Table 20: Shaft-end play
Frame Double row bearing Duplex bearing
STi inches (millimeters)
0.0011 (0.028)
0.0019 (0.048) 0.0007 (0.018)
0.0010 (0.025)
MTi inches (millimeters)
0.0013 (0.033)
0.0021 (0.053) 0.0009 (0.023)
0.0012 (0.030)
LTi inches (millimeters)
Not applicable 0.0010 (0.025)
0.0015 (0.038)
XLT-i inches (millimeters)
0.0014 (0.036)
0.0023 (0.058) 0.0010 (0.025)
0.0015 (0.038)
Maintenance
