2 Installing and Replacing Hardware Parts in Your PC
Replacing the Hard Drive Bay and Speaker Assembly
39
Replacing the Hard Drive Bay and Speaker Assembly
Removing the Assembly
1 Switch off the display and PC. Disconnect all power cables and any LAN
or telecommunications cables.
2 Remove the PC’s cover and front bezel (refer to page 25 for these
instructions).
3 Remove the two
primary hard disk
retaining screws
located on the
front left side of the
chassis and lift the
primary hard disk
drive out of the
hard disk drive bay.
4 Disconnect the
data and power
cables from the
primary hard disk
drive. If you have a
second hard disk
drive installed,
disconnect its
data and power
cables.
5 Remove the two
secondary disk
tray retaining
screws located on
the front centre of
the chassis, then
slide the tray
towards the rear
of the PC and
remove it
.
6 Disconnect the speaker and control panel cables from their connectors
on the system board.
➎
➌
