2 Installing and Replacing Hardware Parts in Your PC
Removing, Replacing and Upgrading Memory
26
Removing, Replacing and Upgrading Memory
NOTE Use only HP memory modules specifically designed for your PC model. To
find out about available accessories for your PC, refer to the HP Accessories
Web site at:
www.hp.com/go/pcaccessories .
Upgrading Memory
Your PC has two pairs of memory sockets for installing either two or four
PC800 RAMBUS Direct RAM (RDRAM) memory modules.
NOTE Each pair of memory sockets must contain identical memory modules
(identical in size, speed and type). That is, sockets
A1 and B1 must contain
identical modules, and sockets A2 and B2 must contain identical modules
(or continuity modules).
If only two RDRAM modules are installed, use the sockets marked A1 and
B1 . The other two sockets ( A2 and B2 ) must contain continuity modules.
Processor
Po
w
er Supply
Connect
or
Secondary
IDE
B2 B2
B1
A2
A1
Primary
IDE
Flopp
y
