2 Installing and Replacing Hardware Parts in Your PC
Removing, Replacing and Upgrading Memory
27
Memory modules for your PC are available from HP or from your
Authorized HP Reseller. To see which memory modules are available,
connect to
www.hp.com/go/pcaccessories , then select HP Memory
and vl800 in the menus.
Removing and Installing a Memory Module
Installing or
Replacing a
Memory Module 1 Switch off the display and PC. Disconnect all power cables and any LAN
or telecommunications cables.
2 Remove the PC’s cover (refer to page 24 for instructions).
3 If you are installing
additional memory
modules then you will
need to remove the
continuity modules. Open
the two retaining clips and
remove the continuity
module from the socket.
If you are replacing an
existing memory module
then open the two
retaining clips and remove the existing memory module the socket
.
Always store any removed memory or continuity module in a safe place
for future use.
4 Install your new memory
modules, ensuring that
the two notches on the
bottom edge of each
memory module is
aligned with those of the
socket. With the two
retaining clips open,
press the memory
module fully into the socket until the retaining clips click into position.
You can also close the retaining clips by hand to ensure that the module
is correctly inserted.
5 Replace the PC’s cover (refer to page 25). Reconnect all the power and
telecommunications cables.
6 Check the Summary Screen to verify the new configuration (refer to
“Viewing the Summary Screen” on page 18)
.
