THE REMOTE CONTROL
NOTES: 1. Even if the input of the horizontal / vertical synchronizing signal (or video signal) stops in the multi picture display, the
mode will not change to power save mode.
2. Please be careful since image retention will occur if display is left in a multi picture display state for a long period of
time
MULTI PICTURE (PinP)
Activating the 4 pictures mode from the TV screen
Pressing the MULTI MODE button one time at the 2 pictures mode will display 4 pictures.
•
Press [A/B] button to select picture A or picture B indicated by a red triangle. For pictures on
right, press
̆ ̄ SELECT buttons to select picture. The selected channel number would
change green.
•
The TV channel can be changed by pressing the
̆ and ̄ PROGRAM UP/DOWN buttons on
the remote control.
•
The audio can only be output from picture A in 4 pictures mode.
•
The same signal input mode cannot be selected for each screens at the same time.
•
Pressing the MULTI PICTURE button at the 4 picture mode will cancel the multi picture mode.
And then, pressing the MULTI PICTURE button again will display the 4 pictures.
•
Refer to the table for 4 pictures mode.
5AV1
3
AV1
AV2
AV3
B1
B2
B3
A
Activating the 12 pictures mode from the TV screen
Pressing the MULTI MODE button one time at the 4 pictures mode will display 12 pictures.
•
Starting from channel 1, preset channels will automatically display in sequence on the 12
windows.
•
This function activates only in TV mode.
•
After several seconds, it refreshes the picture one by one.
•
Pressing the MULTI PICTURE button at the 12 picture mode will cancel the multi picture mode.
And then, pressing the MULTI PICTURE button again will display the 12 pictures again.
•
Pressing the MULTI MODE button at the 12 picture mode will display the 2 pictures
(Split) mode.
5AV1
Sub 1
Sub 2
Sub 3
Main
4 Pictures
ANT
Input terminal
AV1-AV4
AV1, AV2
RGB1
RGB2
Sub
Main
NTSC-M NTSC-M
576i 480i
1080i/50 1080i/60 720p/60 STB Componen
576p 480p
t
ANT
NTSC-M
Ț
AV1-AV4
NTSC-M
ȚȚ
AV1, AV2
576i, 576p
ȚȚ
480i, 480p
ȚȚ
1080i/50
ȚȚ
1080i/60
ȚȚ
720p/60
ȚȚ
RGB1
STB
RGB2
Component
ȚȚ
(
Ț : Available)
