FIRST TIME USE
FRONT PANEL CONTROLS
11
FRONT VIEW
ቢ
MENU/EXIT button
This button allows you to enter the MENU, making it possible to set TV features to your preference without using the remote. This
button also serves as the EXIT button when in MENU mode.
ባ
INPUT/SELECT button
Press this button to select the desired input, AVI to AV4, RGB1 and RGB2. Your selection is shown in the top right corner of the
screen. This button also serves as the SELECT/OK button when in MENU mode.
ቤ
CHANNEL selector
Press these buttons until the desired channel appears in the top right corner of the TV screen. These buttons also serve as
the cursor down (
̄) and up (̆) buttons when in MENU mode.
ብ
VOLUME level
Press these buttons to adjust the sound level. The volume level will be displayed on the TV screen. These buttons also serve as
the cursor left (
̇) and right (̈) buttons when in MENU mode.
ቦ
SUB POWER button
Press this SUB POWER button to turn ON the Plasma television when not using the remote control power button
Cabinet
(front frame) Panel
ቩ
CHANNEL DOWN button
(
SELECT button)
INPUT SELECT button
(OK button)
CHANNEL UP button
(
SELECT button)
• Adjustment buttons are located
on the bottom.
• The back cover is provided with
indications to distinguish the
adjustment buttons.
SUB-POWER button
Control panel
VOLUME
UP/DOWN
buttons
(
ADJUST
buttons)
Main power switch
• The main power switch is located at the back, on the
lower surface.
ቨ
ቧ
ቦ ብ ቤ ባ
ቢ
MENU/EXIT button
• ( ) indicates the function while the MENU is displayed on the screen.
