Henny Penny PRESSURE FRYERS 600 - Manual (Page 52)

Model 500/600
3-15. LID LUBRICATION To extend the life of lid components, lubricate the ball seat and
spindle, following the steps below.
1. Close and latch the lid, and turn the spindle counterclockwise
until it stops.
2. Press down on the front of the cross bar, pull out the release
pin, lift the latch, and raise the cross bar.
3. Using spindle lube (part no. 12124), lubricate the ball seat in
the center of the lid cover.
4. Turn spindle clockwise until it stops and then lubricate the
threads on the spindle using the spindle lube.
5. Turn the spindle counterclockwise until it stops, line up the lid
cover with the cross bar, pull the release pin out, and firmly
press the cross bar back into place.
6. The fryer is now ready for use.
3-28 1207
