Hp installation (other than primary cpu), Hp installation (other than primary cpu) 3-9 – HP Model 743 PC User Manual
Page 73
3-9
Typical Installation in a VME Card Cage
HP Installation (Other than Primary CPU)
HP Installation (Other than Primary CPU)
The Model 743 board computer’s P2 connector has a local bus on user-
defined pins. The VME slot used by the Model 743 must make no connec-
tions to J2/P2, rows A and C.
Refer to Chapter 7 of IEEE STD 1014-1987 for more information on user-
defined pins in VME backplane connectors.
