3-6
Typical Installation in a VME Card Cage
Board Computer Installation
Board Computer Installation
Tools Required
Installing the board computer requires the following tools:
Preliminary Requirements
Before you install the board computer into the VMEbus card cage, read the
steps in “Configuring the VMEbus Card Cage,” earlier in this chapter.
Installing a Single VME Slot 743 into an HP Card Cage
Follow these steps to install the board computer into the VME card cage:
1 Position the board computer at the desired slot and slide it into the card
cage until it seats properly and the Front Panel is flush against the card
cage.
2 Push both ejector levers in until they are flush with the front panel.
3 Engage and tighten the captive screws (labeled 1 and 2 in Figure 3-1) at
each end of the board computer. These screws hold the computer in the
VME card cage.
Table 3-3 Required Tools for Installation
Tool Used For
Grounding wrist strap
(supplied with the installation kit) Preventing static discharge problems
No. 1 Pozidriv screwdriver Attaching accessory cards
5 mm (
3
/
16
-inch) nutdriver
Attaching accessory cards
Light-duty flat-tipped screwdriver Attaching accessory cards
