HP XU800 User Manual
Page 132
132
7 Connectors and Sockets
VRM
VRM
Pin
Signal
Pin
Signal
A1
5Vin_5
B1
5Vin_2
A2
5Vin_4
B2
5Vin_1
A3
5Vin_3
B3
5Vin_0
A4
12Vin_1
B4
12Vin_0
A5
12Vin_2
B5
SENSE
A6
ISHARE
B6
OUTEN
A7
VID0
B7
VID1
A8
VID2
B8
VID3
A9
VID4
B9
PWRGOOD
A10
VCCP10
B10
GND0
A11
GND5
B11
VCCP4
A12
VCCP9
B12
GND10
A13
GND4
B13
VCCP3
A14
VCCP8
B14
GND9
A15
GND3
B15
VCCP2
A16
VCCP7
B16
GND8
A17
GND2
B17
VCCP1
A18
VCCP6
B18
GND7
A19
GND1
B19
VCCP0
A20
VCCP5
B20
GND6
