113
6 Tests and Error Messages
MaxiLife Test Sequence and Error Messages
Diagnostics Runs a set of diagnostics assessing the system’s components. Results of the
tests are displayed on the LCD status panel, one after another, when the
LCD
buttons are pressed.
It is possible to cancel the diagnostic process and return to the previous
state by pressing the LCD key labelled “Back”. When “OK” is selected, the
main power supply is started but the PC Workstation is not allowed to do a
normal boot. The purpose of this is to allow only those devices that can be
tested to answer the diagnostic request from MaxiLife.
Components are tested in sequence when the “Next” button is pressed.
When they have all been checked, a diagnostic screen is shown. Depending
on the result of the diagnostics, the screen could indicate either:
OK or FAIL.
At the end of the test, you can exit the diagnostic mode by pressing the
LCD button.
