72
HP Media Center PC Getting Started Guide
Memory Insertion Guide
A Activity light
B Upper-left slot
C Lower-left slot
D Upper-right slot
E Lower-right slot
A
E
D B
C
Card Insert the media 4-slot reader location
CompactFlash Type 1 media Receptacle edge (holes) C (lower-left)
CompactFlash Type II media Receptacle edge (holes) C (lower-left)
IBM Microdrive disk drive Receptacle edge (holes) C (lower-left)
Secure Digital (SD) memory card Facing up
D (upper-right)
Mini Secure Digital (MiniSD)
Memory Card
*
Facing up
D (upper-right)
MultiMediaCard (MMC) Facing up
D (upper-right)
Reduced size MultiMediaCard
(RSMMC)
*
Facing up
D (upper-right)
n
Some memory cards,
such as CF Ultra/III,
are not compatible
with the memory
card reader that
came with your
HP Media Center PC.
MiniSD
MMC
RSMMC
