18
HP Media Center PC Getting Started Guide
You may need to purchase extra cables separately.
Your HP Media Center PC box may not include all
the cables you need for your PC setup and may vary
by model.
For example, you may want to use an S-video cable
to connect the TV Out on the PC to your TV, if your
TV has an S-video input connector.
DVI-I or DVI-D cable Digital Video Out. Plug cable into a
DVI-I or DVI-D input of an HDTV-
capable TV or monitor.
TV coaxial cable Plug cable into a TV signal source
input connector from cable set-top
boxes or antennas.
Remote IR cable
(Infrared transmitter)
NOTE: PC includes 1
with single TV tuner or
2 with dual-tuner
option. Remote IR cable. Used to control TV
signal source from set-top box.
Splitter Used to connect one signal source to
two RF inputs on your PC.
RCA stereo RCA red and white ends. Used for TV
signal source Audio In and Audio Out
connectors to TV.
Cable Name Description (Continued)
2 Way Splitter
