1. Before Use

16

Names and Functions of Components

Camera body

26 25

29

27

28

9

12

22

30

16

15

17

1314

8

11

10

21

20

24

23

19

18

1

4

2 3

19

5 6

7

1

WIRELESS connection lamp

(P284)

2

Status indicator

(P37)

3

Camera ON/OFF switch

(P37)

4

[

] (Exposure Compensation) button

(P106)

5

[

] (ISO sensitivity) button

(P108)

6

[

] (White Balance) button

(P111)

7

Focus distance reference mark

(P104)

8

[Fn1] button

(P59)

9

Motion picture button

(P161)

10

Front dial

(P43)

11

Shutter button

(P41)

12

Self-timer indicator

(P134)

/

AF Assist Lamp

(P238)

13

Mode dial

(P42)

14

Mode dial lock button

(P42)

15

Stereo microphone

(P168)

• Be careful not to cover the microphone with

your finger. Doing so may make sound difficult
to record.

16

Hot shoe (Hot shoe cover)

(P152)

• Keep the hot shoe cover out of reach of

children to prevent swallowing.

17

Drive mode dial

(P114)

18

Flash synchro socket
(Flash synchro socket cap)

(P153)

• Use the flash with a synchronization voltage of

250 V or less.

• Connect the supplied BNC conversion cable

(for TC IN/OUT) when synchronizing the time
code with an external device.

(P170)

19

Shoulder strap eyelet

(P19)

20

[MIC] socket

(P205)

21

Headphone socket

(P208)

22

[HDMI] socket

(P198

,

329)

23

USB socket

(P335

,

340)

24

Cable holder mount

(P199)

25

Lens release button

(P34)

26

Lens lock pin

27

Mount

28

Sensor

29

Lens fitting mark

(P34)

30

Preview button

(P75)

/Function button (Fn6)

(P59)
