DFCM ♦ ProLinx Gateway DFCM Protocol Configuration
DF1 Master/Slave Driver Manual
ProSoft Technology, Inc. Page 37 of 88
October 15, 2010
6.4 DF1 Slave Configuration
The following parameters are required only if the port is to be configured as a
Slave.
6.4.1 First File
First File : 7 #First file number for SLC simulation
This parameter is used when a request for a file is received on the
communication port. This field is required when responding to PLC5 and SLC
DF1 commands. Use this parameter to define the virtual file(s) to be simulated on
the module. Enter a value in the range of 0 to 100.
6.4.2 File Size
Range 1 to 1000
This parameter specifies the size of each file to be simulated on the module. All
files simulated are defined to have the same assigned size.
6.4.3 File Offset
This parameter sets the database register location of the first element in the first
file simulated in the module. All offsets in the first file and subsequent files will be
computed using the address specified. Enter a value in the range of 0 to 4999.
