User’s Manual of WNAP-1260
-66-
Chapter 8. Web Configuration for the Router Mode
In the Router mode, WNAP-1260 works as a domestic gateway.
8.1. Router Mode Topology
In Router Mode, the NAT (Network Address Translation) function and DHCP server are both enabled,
and all wireless clients share the same public IP assigned by ISP through WAN port of the WNAP-1260.
The WNAP-1260 is supposed to connect with the Cable / xDSL Modem by UTP cable.
8.2. Hardware Setting
Set the three-way switch on the side panel to AP after WNAP-1260 is powered on.
8.3. Running Status
Log in to the configuration page after the system is started.
Click Running Status and the extended navigation menu is shown as follows:
Click the submenu to enter a specific configuration page.
8.3.1. System Status
Choose Running Status > System Status and the System Status page is displayed.
